V142 VCM2 LandRover & Jaguar.1. Used for the majority of the JLR SDD diagnostic applications.2. It is simple and easy to use.3. Support Multi Languages.

Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142 is a one of our OBD2 tool for Jaguar Tools, you can buy Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142 from zobdii.com.

Wholesale Top quality X-PROG Box ECU Programmer, Kess ECU Programmer, SBB Pro2 Key Programmer, Volvo 88890300 Vocom Interface, Cummins INLINE 7 Data Link Adapter

images of Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142

Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142Newest VCM2 Diagnostic Scanner For LandRover & Jaguar V142

VCM2 for LandRover and Jaguar V142
Buy it for 6 Reasons:

1. Software Version: V142
2. Most cost effective Land Rover pass-thru
3. Best suited for current and future vehicles
4. Easy to update for J2534 new functionality
5. It is simple and easy to use.
6. Multi Languages: Deutsch,English,Espano,francais, italiano nederlands, Portugues(European) Russian,Japanese,Chinese

VCM2 for LandRover & Jaguar Descriptions:
1. JLR Approved device
2. Replacement for JLR SDD VCM
3. Covers CAN, & ISO9141 vehicle networks
4. 12ft USB cable as standard included
Jaguar & Land Rover Vehicle Coverage:

JLR Vehicles Supported?
Defender Yes
Discovery /LR3/LR4 Yes
Range Rover Sport & New Range Rover Sport Yes
Range Rover Yes*
New Range Rover Yes
Freelander /LR2 Yes
Evoque Yes
XJ – X300/X308 No
XJ - X350 No
XJ - X351 Yes
XJS No
XK – X100 No
XK - X150 Yes
XF Yes
S-Type No
X-Type No
F-Type Yes
(Yes) – Vehicle line fully supported:
(Yes*) - Vehicle line fully supported apart from viewing Data logger signals from both ECM and TCM
modules simultaneously on 2006MY variants :
(No) - Vehicle Line Not supported
VCM2 for LandRover & Jaguar Functions:
1. The VCM2 for Land Rover connects directly to the vehicle OBDII (diagnostic) connector and then to a laptop via a USB cable for use with SDD.
2. Once the J2534 DLL files are loaded, this product will allow normal operation with the JLR SDD diagnostic tool.
3. The device is designed as a replacement pass-through vehicle communications device that can be used for the majority of the JLR SDD diagnostic applications.
4. Only SCP communications are not possible with this device.

How does the VCM2 for Land Rover operate in J2534 mode?
1. Please read the user manual firstly before using, install the software after watching the video or user manual in the DVD
2. Connect the J2534 device to the vehicle OBDII connector (the device powers from the vehicle).
3. Connect the 12ft USB cable to the J2534 device and the other end to the SDD laptop.
4. The red vehicle power (PWR) LED will illuminate to show that the device is powered.
5. During communication with the vehicle the status (STS) LED will flash green.
6. The device interacts with the SDD diagnostic tool in the same way as the existing VCM.
VCM2 for LandRover & Jaguar Package List:
1pc x VCM2 for LandRover Main Unit
1pc x OBD2 Cable
1pc x USB Cable
2pcs x CD
1pc x Carrying Case
